Jan 1, 1345
Pontie Vecchio
Medieval bridge builders borrowed the form of the stable Roman arch bridge, but began to build upward, layering on dwellings and places of business. Florence’s Ponte Vecchio (“Old Bridge”) is one of the most famous inhabited bridges, known both for its stunning setting and for the fact that it is still in use. Spanning the narrowest point of the Arno, the Ponte Vecchio sustained significant damage in the great Florence flood of 1966. -
Jade Belt
Also called camels back bridge
example of mood bridge style
connects the green river with white marble and stone -
Iron bridge
first fully constructed bridge with all iron
Closed to all transportation other than walking
Workers built it one piece at a time -
Brooklyn bridge
First to use underwater caission chambers
the structure was built with many technical difficulties and dangerous conditions -
Garabit Viaduct
Eiffel made this bridge
He based his design on open triangles
These triangles help support the bridge, by letting the wind pass through it -
Firth of Forth bridge
An example of cantilever bridge design
The cantilever design is made for small structures and projects -
Quebec bridge collapse
something wrong in design made the bridge itself heavier than the weight limit it can hold it collapsed twice -
Golden gate bridge
built in an earthquake zone
Until 1964 is was the biggest suspension span at 8,981ft and also held the record for the worlds tallest suspension towers until 1998 -
Tacoma Narrows Bridge Collapse
Collapsed 4 months after the grand opening
no one was killed
designed to be more elligant than the Golden Gate bridge -
First Iron Bridge
Was made in Philadelphia and its Countryside/Lehigh Valley -
Silver Bridge Collapse
Collapsed because of heavy traffic loads -
Sunshine Skyway
The Sunshine Skyway once collapsed
When rebuilt, the Skyway was so close to the water, if you looked out the window, you could see the water up close -
Mianus Bridge
One of the pins in the construction sheared causing it to be very dangerous and collapsed, with a tracter trailer truck crossing over and then broke through to the ground -
Songsu Bridge Collapse
Central section of the bridge sheared off -
Rainbow Bridge Collapse
The steel was very inferior quality when investigated -
Hintze-Ribeiro Bridge Collapse
The reason why the bridge collapsed is still a mystery to solve -
Alcantara Bridge
636 foot span was built to last forever
Trajan ordered construction of a bridge over the Tagus River at Alcantara
